Features:
●High transmission PMMA opal diffuser
●Body manufactured in cold-rolled steel with durable white powder coat finish
●LED options: Samsung as standard, and Philips, Osram & Epistar available on request
●Driver options: non-dimmable, and 1-10V, DALI, DSI dimmable available, Sensor and emergency batteries kit available on request
●Good color rendering of CRI>80
●Even light distribution
●Superior thermal performance of LED board, leading to a longer life
●Long working life with high efficiency for energy saving
Mounting: surface mounted
Key Applications:
Office buildings, schools, universities, libraries, hospitals, etc.
Photometric:
Specification:
●High transmission PMMA opal diffuser
●Body manufactured in cold-rolled steel with durable white powder coat finish
●LED options: Samsung as standard, and Philips, Osram & Epistar available on request
●Driver options: non-dimmable, and 1-10V, DALI, DSI dimmable available, Sensor and emergency batteries kit available on request
●Good color rendering of CRI>80
●Even light distribution
●Superior thermal performance of LED board, leading to a longer life
●Long working life with high efficiency for energy saving
Mounting: surface mounted
Key Applications:
Office buildings, schools, universities, libraries, hospitals, etc.
Photometric:
Specification:
Product Code |
Fixture Size (mm) |
Wattage |
Lumen @4000K |
CCT (K) |
CRI |
Power Factor |
Carton Size (cm) |
Qty/ctn (pcs) |
MQG-LED-215A(S) |
1195x295x65 |
32w |
3306lm |
3000-6500K |
>80 |
>0.9 |
125x35x15 |
2pcs |
MQG-LED-220A(S) |
1195x295x65 |
40w |
4000lm |
3000-6500K |
>80 |
>0.9 |
125x35x15 |
2pcs |
MQG-LED-222A(S) |
1195x295x65 |
45w |
4200lm |
3000-6500K |
>80 |
>0.9 |
125x35x15 |
2pcs |
Other lengths, wattages and lumens are available on request.
