Features:
●Adjustable with 60° tilt and 355° rotation
●Die-cast aluminium body ensures excellent heat dissipation
●High efficiency aluminum reflector with glass
●COB options: Citizen, Cree and Epistar
●Remote drivers: Non-dimmable, DALI or 1-10V on request
●IP20, Ta25, CRI>80
●Superior thermal performance, leading to a longer life
Installation:
Recess mounted
Key Applications:
Shopping Centers, Supermarkets, hotels, restaurants, exhibition, etc.
| Photometric: |
Drawing: |
 |
 |
|
Product Code |
Diameter Ø (mm) |
Cutout Ø (mm) |
Height (mm) |
Wattage |
Lumen @4000K (lm) |
CCT (K) |
CRI |
Power Factor |
Carton Size (cm) |
Qty/ctn (pcs) |
|
MQT-LED-0308M |
85 |
78 |
78 |
8w |
536 |
3000-6500K |
>80 |
>0.9 |
50x37.5x25 |
24 |
|
MQT-LED-0415M |
130 |
120 |
115 |
15w |
1300 |
3000-6500K |
>80 |
>0.9 |
60x45x28 |
24 |
|
MQT-LED-0520M |
165 |
157 |
143 |
20w |
2000 |
3000-6500K |
>80 |
>0.9 |
57x35x34 |
12 |
|
MQT-LED-0629M |
190 |
175 |
155 |
29w |
2830 |
3000-6500K |
>80 |
>0.9 |
63x42x38 |
12 |
